Description
OptiClimate PRO3 Cooler
2000 PRO3 Specs
The OptiClimate 2000 PRO 3 water-cooled air conditioner has a cooling capacity of 2kW. This new OptiClimate 2000 PRO 3 is specifically designed for small spaces.
- Name: OptiClimate 2000 PRO3
- Voltage:230V
- Cooling capacity:2000W
- Water usage: 0,6-1,2 L/min***
- Power consumption:500W
- Phase:1o2*
- Connection:
- 1 phase D16 2,5mm2 cable
- 3 phases D16 2,5mm2 cable
- Heating elements:2x1300W
- Dehumidifies capacity: 35 L/24h**
- Dimensions:100x50x42
- Weight: 53kg
** At 80% humidity and a ambient temperature of 30°C.
*** At cooling water temperature of 6°C to 20°C.
3500 PRO3 Specs
The OptiClimate 3500 PRO3 water-cooled air conditioner has a cooling capacity of 3,5kW, uses between 1 and 2 liters of water x minute and has 2x1500W heating elements.
- Name: OptiClimate 3500 PRO3
- Voltage: 230V
- Cooling capacity: 3500W
- Water usage: 1,0-2,0 L/min***
- Power consumption: 740W
- Phase: 1o2*
- Connection:
- 1 phase D16 2,5mm2 de cable
- 3 phases D10 2,5mm2 de cable
- Heating elements: 2x1500W
- Dehumidifies capacity: 55 L/24h**
- Dimensions: 100x50x42
- Weight: 57kg
** At 80% humidity and a ambient temperature of 30°C.
*** At cooling water temperature of 6°C to 20°C.
6000 PRO3 Specs
The OptiClimate 6000 PRO3 water-cooled air conditioner has a cooling capacity of 6kW, uses between 2 and 4 liters of water x minute and has 3x1500W heating elements.
- Name: OptiClimate 6000 PRO3
- Voltage: 230-400V
- Cooling capacity: 6000W
- Water usage: 2,0-4,0 L/min***
- Power consumption: 1450W
- Phase: 1o3*
- Connection:
- 1 phase D25 4,0mm2 de cable
- 3 phases D16 2,5mm2 de cable
- Heating elements: 3x1500W
- Dehumidifies capacity:100 L/24h**
- Dimensions: 115x53x43
- Weight: 80kg
** At 80% humidity and a ambient temperature of 30°C.
*** At cooling water temperature of 6°C to 20°C.
10000 PRO3 Specs
The OptiClimate 10000 PRO3 water-cooled air conditioner has a cooling capacity of 10 kW, uses between 3 and 6 liters of water x minute and has 3x2000W heating elements.
- Name: OptiClimate 10000 PRO3
- Voltage: 230-400V
- Cooling capacity: 10000W
- Water usage: 3,0-6,0 L/min***
- Power consumption: 2150W
- Phase: 1o3*
- Connection:
- 1 phase D35 4,0mm2 de cable
- 3 phases D20 2,5mm2 de cable
- Heating elements: 3x2000W
- Dehumidifies capacity: 170 L/24h**
- Dimensions: 115x56x50
- Weight: 120kg
** At 80% humidity and a ambient temperature of 30°C.
*** At cooling water temperature of 6°C to 20°C.
15000 PRO3 Specs
The OptiClimate 15000 PRO3 water-cooled air conditioner has a cooling capacity of 15 kW, uses between 5 and 9 liters of water x minute and has 3x2700W heating elements.
- Name: OptiClimate 15000 PRO3
- Voltage: 400V
- Cooling capacity: 15000W
- Water usage: 5,0-9,0 L/min***
- Power consumption: 3100W
- Phase: 3*
- Connection:
- 3 phase D25 4,0mm2 de cable (the compressor of this unit is divided over 3 phases)
- Heating elements: 3x2700W
- Dehumidifies capacity: 270 L/24h**
- Dimensions: 121x70x54
- Weight: 160kg
** At 80% humidity and a ambient temperature of 30°C.
*** At cooling water temperature of 6°C to 20°C.
